APPLICATION

Centrifugal irrigation pumps with single impeller. Suitable to pump clean water or non-aggressive liquids charged with small solid impurities. To be used in flow irrigation systems in gardening and agriculture and in industrial fittings.

  • TCB 100
  • TCB 150
  • TCBt 150
  • TCB 60
  • TCBt 60
  • TCB 65
  • TCBt 65
  • TCB 70
  • TCBt 70
  • TCB 102
  • TCBt 102
  • TCB 152
  • TCBt 152
  • TCB 203/A
  • TCBt 203/A
  • TCB 203/B
  • TCBt 203/B
  • TCB 303/A
  • TCBt 303/A
  • TCB 303/B
  • TCBt 303/B
  • TCB 403/A
  • TCBt 403/A
  • TCB 403/B
  • TCBt 403/B
  • TCB 454/A
  • TCBt 454/A
  • TCB 454/B
  • TCBt 454/B
  • TCB 554/A
  • TCBt 554/A
  • TCB 554/B
  • TCBt 554/B

OPERATING CONDITIONS

- Liquid temperature up to 35°C (for home use according to EN 60335-2-41)

  Temperature max. liquid: 90°C (for other uses)

- Ambient temperature up to 40°C

- Total suction lift up to 7 mt.

- Continuous duty

MOTOR

- Single-phase 230V-50Hz

- Three-phase 230/400V-50Hz

- Two-Pole induction motor (n = 2850 min-1)

- Insulation Class F

- Protection IP 55

MATERIALS

- Pump body Cast Iron

- Motor Support Cast Iron

- Impeller Cast Iron

- Shaft with rotor Stainless Steel AISI 304

- Mechanical seal Ceramic/Graphite/NBR

Water Pumps Made In ITALY
